ZMC-CHSJ-GH
ZMC-CHSJ-GH GREENHOUSE FILM BLOWN MACHINE
Enquiry about ZMC-CHSJ-GH
- Description
Description
ZMC-CHSJ-GH GREENHOUSE FILM BLOWN MACHINE
| Model | □N-120/3200 □N-180/3500 □N-200/4000 |
| Film width (mm) | □3000-12000mm □3000-16000mm □3500-24000mm |
| Film thickness | 0.006-0.04mm |
| max output
|
□300kg/h □600kg/h □900kg/h According to different width, thickness of film, die size and raw material characteristics to change |
| suitable material | LDPE/LLDPE/HDPE |
| Diameter of screw | □Φ120,30/1 □Φ180,30/1 □Φ220,30/1
SACM 645 ,bimetallic ，five years guarantee |
| Gear box | □420# □560# □630# Extruder special hard gear reducer，tooth grinding teeth hardened, internal and external oil circulation system |
| Take up roller(mm) | □3200mm □3500mm □4000mm |
| Overall dimension（L*W*H）m | □12*5*11 □15*5*22 □16*8*22.4 |
Note: the above specifications, dimensions & design characteristics are subject to change without notice
Optional device:
Automatic Hopper Loader
Film Surface Treater
Rotary Die
Oscillating Take up Unit
Two Stations Surface Winder
Chiller
Heat Slitting Device
Gravimetric Dosing Unit
IBC(Internal Bubble Cooling Computer Control System)
EPC(Edge Position Control)
Electronic Tension Control
Manual mechanics screen changer
Edge material recycling machine
